Ambient mist fire fighting nozzles is FOR SALE

Throughout his decades of experience as a firefighter, William Lowry developed fire suppression technology that protected firefighters from harm and caused far less fire and water material damage than the industry standard methods.

Firefighting equipment “Ambient Mist Technology” efficiently extinguishes fires, displaces smoke particles, carcinogens, and other airborne pollutants.

Other advantages of this system include reducing water and fire damage while conserving the available water resource.

Fires are often so devastating because victims lose everything, not just to fire damage but also to water damage. The Ambient Mist technology uses, which uses a variable low to high pressure settings to extinguish fires that reduces water usage and damage.

Find out more

Background

Fire Test Burn for Firefighting Nozzle and Spray Mist Sprinkler Protection Device.

This test took place at Quinte West Fire training facility Murray Ward Quinte West On (Trenton). Chief John Whalen was in charge with his crewmen to do the testing in an unbiased and fair manner. The test began with a burn in a small well-ventilated building which should have presented some challenges but the “Ambient Mist” system worked very efficiently extinguishing the fire completely with approximately three (3) gallons of water. High pressure water setting was used for this application requiring a small amount of water that resulted in negligible water damage.

A second test was set in a much larger area with a mix of combustibles that were piled high. The flammable materials included wood pallets, straw, tar, oil, gasoline, paper and other combustibles which made a toxic witches brew.

The structure was a large oil tank about 25 feet long and 12 ft. in diameter lying on its side with a large door opening giving the fire a high level of oxygen availability. Just prior to the test, Fire chief Whalen initially indicated that this fire test setting would produce too great a fire for the Ambient Mist to be successful. Turned out the test results proved him wrong and they succeeded in a very efficient manner.

The firefighters required to wear full turn-out gear to approach the fire because of intense heat and smoke. Using a handheld heat sensor tool, the fire temperature was established in excess of 1200 degrees. After an initial water application with the Ambient Mist portable wand and sprinkler head, the temperature dropped 300 degrees. Then after changing the head (applicator) tip to a double house sprinkler head, the temperature dropped another 300 degrees. The initial six hundred (600) degree temperature drop was accomplished in sixty-two (62) seconds. The fire was then extinguished within minutes.

This Ambient Mist sprinkler system test exceeded expectations by all present.

The test pressure used was between 45psi-62psi.

This test was recorded by video and witnessed by approximately twenty-five (25) firefighters along with the Quinte West Fire Chief John Whalen.

“A NEW AGE OF FIRE SUPPRESSION HAS FINALLY ARRIVED”, Contact us today for more information on Ambient Mist Technology.

We Specialize In

· Portable Firefighting Nozzles

· Chimney Fire Nozzle

· Firefighting Equipment

· Ambient Mist Technology

· Firefighting Sprinkler Nozzles

Patented Products ready for Sale

The Ambient Mist Chimney Nozzle

Our brass Chimney nozzle is unique due to its design. The Chimney Nozzle is used by lowering the device down a chimney while water is supplied, thereby creating an ambient mist as the chimney tool is lowered. The ambient mist extinguishes the fire quickly with little or no water damaged caused to the flute making it more efficient. The Chimney nozzle has no handle and is directly attached to a water hose line.

It has a four (4) nozzle head that puts out 8 G.P.M (gallons per minute) and 8 P.S.I. (pounds for square inch) All nozzles are tested to work from 0.03 to 125 P.S.I. This nozzle is intended for use against chimney or silo fires by attaching it to any available hose types or a firefighting hose. A hose attachment reducer can be used to adapt this nozzle to any size hose. This system will put out fires by smothering them with the ambient mist technology.

This nozzle system can be used for all class types of fires including A.B.C. or D.

Manifest

The Ambient Mist Nozzles

This brass five nozzle sprinkler head provides an ambient mist spray for efficient and safe methods of fire extinguishing. Our nozzles can be used with either low or high pressure, at rates up to 125 pounds per square inch. This firefighting nozzle system uses 12 gallons of water per minute.

The nozzle has no moving parts

The nozzle should be attached to a 1 ½” to 1 ¾’ hose or larger by using a threaded adapter.

This nozzle system includes a wand hand hold attachment equipped with an on/off ball valve.

Install this brass nozzle onto a permanent water sprinkler system or use it with the wand handle with lightweight, portable firefighting equipment. This sprinkler requires minimal water pressure to operate, but as the pressure is increased more water vapor is created.

This nozzle system includes a wand hand hold attachment equipped with an on/off ball valve.

It can be used on all types of fires A.B.C. or D. It can be used as a “first response” on site for all types of fires including house, vehicle, grass, forest and building firs etc.…

Manifest

The Ambient Mist Home Sprinkler

Preserve water and suppress fires with this water efficient and effective original Sprinkler Nozzle. This new low to high water pressure technology rapidly puts out fires without causing tones of water damage. Unlike existing devices, the Me technology does not require large amounts of water.

Use this economical firefighting solution on all types of fires using low water pressures. Replace current sprinkler systems in homes, high rise buildings, condos commercial and industrial applications to extinguish fires. Our design will result in reduced consequential water damages and save lives with our highly efficient ambient mist technology. When our sprinkler nozzle is activated, a fine water mist is produced from the four-sprinkler nozzle tip assembly.

The Ambient Mist nozzles can be retrofitted to any existing sprinkler system.

This system also leaves a minimum of 5% oxygen in the air, reducing instances of death due to lack of oxygen.

The sprinkler system is designed to extinguish virtually all building combustibles, electrical fires, flammable liquids and gases with minimal water damage.

This sprinkler head design extinguishes Class A, B and C fires.

Furthermore, for increased efficiency, the sprinkler can be positioned at any vertical or horizontal room position such as ceiling, floor or wall levels. This system does not require gravity to work and sprinklers can be installed at any angle position.

After the fire has been suppressed, the device can be reset by turning the lever back to its closed position and inserting a new frangible bulb into the sleeve.

NOTE: All Fire fighting nozzles include an integral water filtering system.

Efficient Fire Extinguishing

With other fire suppression sprinkler systems, most fires big or small require massive amounts of water at high pressure to extinguish them. These systems cause a great deal of unwanted water damage.

Ambient Mist firefighting Nozzles reduce water damage by generally using greatly reduced amounts of water at lower pressures and works on all types and classes of fire. Manifest
